bizhub C3320i system specifications

identity



Specifications
SYSTEM SPECIFICATION
Panel size/resolution 7” / 800 x 480
System memory (standard/max) 4,096 MB
System hard drive 16 GB (standard)
Interface e 10/100/1,000-Base-T Ethernet; USB 2.0;
Wi-Fi 802.11 b/g/n (optional)
Network protocols TCP/IP (IPv4/IPv6); SMB; LPD; IPP; SNMP;
HTTP(S); AppleTalk; Bonjour
Automatic document feeder (standarrd) Up to 80 originals; A6–A4; 50–128 g/m²; Dualscan ADF
Paper input capacity (standard/max) 600 sheets / 1,100 sheets
Paper tray input (standard) 1x 500 sheets; A6–A4; custom sizes; 60–210 g/m²
Paper tray input (optional) 1x 500 sheets; A4; 60–90 g/m²
Manual bypass 100 sheets; A6–A4; custom sizes; 60–210 g/m²
Automatic duplexing B5–A4; 60–210 g/m²
Finishing modes (optional) Group; Sort; Staple (offine)
Output capacity (standard) Max. 250 sheets
Power consumption 220–240 V / 50/60 Hz; Less than 1.45 kW
System dimension (W x D x H) 420 x 528 x 572 mm (without options)
System weight Approx. 38.4 kg (without options)

Back to Top

Print resolution 1,800 (equivalent) x 600 dpi; 1200 x 1200 dpi
Page description language PCL 6 (XL3.0); PCL 5c; PostScript 3 (CPSI 3016); XPS
Operating System Windows 7 (32/64); Windows 8/8.1 (32/64); Windows 10 (32/64);
Windows Server 2008 (32/64); Windows Server 2008 R2;
Windows Server 2012; Windows Server 2012 R2;
Windows Server 2016; Windows Server 2019;
Macintosh OS X 10.10 or later; Unix; Linux; Citrix
Printer fonts 80 PCL Latin; 137 PostScript 3 Emulation Latin
Mobile printing AirPrint (iOS); Mopria (Android);
Konica Minolta Mobile Print (iOS/Android/Windows 10 Mobile);
Mobile Authentication and Pairing (iOS/Android)
Optional: WiFi Direct

Back to Top

Scan speed (mono/colour) ) Up to 28/28 ipm in simplex
Up to 56/56 ipm in duplex
Scan modes Scan-to-eMail (Scan-to-Me); Scan-to-SMB (Scan-to-Home);
Scan-to-FTP; Scan-to-USB; Scan-to-WebDAV; Scan-to-URL
File formats JPEG; TIFF; PDF; Compact PDF; Encrypted PDF; XPS; Compact XPS; PPTX
Scan destinations 2,100 (single + group); LDAP support

Back to Top

Imaging technology Laser
Toner technology Simitri® HD polymerised toner
Copy/print speed A4 (mono/colour) Up to 33/33 ppm
Auto duplex Speed A4 (mono/colour) Up to 33/33 ppm
1st copy out time A4 6.0/7.2 sec
Warm-up time Approx. 13 sec. in mono; 15 sec. in color2
Copy resolution 600 x 600 dpi
Gradation 256 gradations
Multicopy 1–9,999
Original format A6–A4; Custom sizes
Magnification 25–400% in 0.1% steps; Auto-zooming

Back to Top

Fax standard Super G3 (optional)
Fax transmission Analogue; i-Fax; Colour i-Fax; IP-Fax
Fax resolution Up to 600 x 600 dpi
Fax compression MH; MR; MMR; JBIG
Fax modem Up to 33.6 Kbps
Fax destinations 2,100 (single + group)

Back to Top

DESCRIPTION
LK-116 Antivirus Bitdefender® Antivirus provides real time scanning
of all incoming and outgoing data

Back to Top

FK-517 Fax board Super G3 fax; digital fax functionality
UK-221 Wireless LAN Wireless LAN and wireless LAN Access Point Mode
EK-P08 USB I/F kit USB keyboard connection
EK-P09 USB I/F kit USB keyboard connection; Bluetooth
EK-P10 NFC interface To connect with Android mobile devices
EK-P11 I/F cable for CSRC modem GPRS modem connection for CSRC
AU-102 Biometric authenticaton Finger vein scanner
ID card reader Various ID card technologies
MK-P08 Mount kit Installation kit for ID card reader

Back to Top

Security Functions (standard) IP filtering and port blocking; SSL2; SSL3 and TLS1.0/1.1/1.2
network communication; IPsec support; IEEE 802.1x support;
User authentication; Authentication log; Secure print; Kerberos;
Hard drive data encryption (AES 256)
Security Functions (optional) Antivirus realtime scanning (Bitdefender®)
Accounting (standard) Up to 100 user accounts; Active Directory support (user name +

password + e-mail + smb folder); User function access definition
EAccounting Functions (optional) Biometric authentication (finger vein scanner);

ID card authentication (ID card reader);
Authentication by mobile device (Android/iOS)
Software Net Care Device Manager; Data Administrator;
Web Connection; Print Status Notifier; Driver Packaging Utility;
Log Management Utility

Back to Top

WT-P03 Working table Authentication device placement
KP-P03 10-Key pad For use instead of touchscreen
KH-P02 Keyboard holder To place USB keyboard
MK-P09 Mount kit Installation kit for Air cleaning unit

Back to Top

PF-P20 Paper tray 500 sheets, A4, 60-90 g/m²
PF-P22 Height adjustment unit To achieve comfortable height for operation
DK-P04x Copier desk Provides storage space for print media and other materials

Back to Top

FS-P04 Off-line stapler 20-sheet of-line stapling
2 When equipped with Automatic Document Feeder DF-714 option.

Back to Top

– All specifications refer to A4-size paper of 80 g/m² quality..
– The support and availability of the listed specifications and functionalities vary depending on operating systems, applications and      network protocols as well as network and system configurations.
– Some of the product illustrations contain optional accessories.
– Specifications and accessories are based on the information available at the time of printing and are subject to change without     notice.
– Konica Minolta does not warrant that any specifications mentioned will be error-free.
– All brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
